The Alpha APS CNC Series machine includes an 8-position tool rack. The tool rack move together with the machine gantry, which will save the tool change time. When changing the tool, the cylinder will punch the tool rack out and then change the tool. After the tool change is finished, the tool rack go back and then the spindle start to work.
Overview
Quick Details
- Condition:
-
New
- CNC or Not:
-
CNC
- Warranty:
-
1 year
- After-sales Service Provided:
-
Online support
- Place of Origin:
-
Shandong, China
- Brand Name:
-
Alpha
- Voltage:
-
380V/220V or Customer made
- Certification:
-
CE ISO9001
- Dimension(L*W*H):
-
1200*25000*200mm
- Power (kW):
-
9
- Applicable Industries:
-
Construction works , Advertising Company, Furniture
- Key Selling Points:
-
Multifunctional
- Weight (KG):
-
2000
- X,Y,Z Traveling Positioning Accuracy:
-
±0.02/2000mm
- Table Surface:
-
Vacuum and T-slot
- X,Y,Z Rail and Transmission:
-
X Y axis helical gear transmission, Z axis Taiwan TBI Ball Screw
- Max. Rapid Travel Rate:
-
60m/min
- Max. Working Speed:
-
40m/min
- Spindle Speed:
-
0-24000RPM
- Working Voltage:
-
AC380V/3PH/50Hz(option:220V)
- Operating System:
-
Taiwan LNC
- Software capabilities:
-
Option: Vectric Aspire, Type3, Ucancam, Artcam, Solidworks, etc.
- Running Environment:
-
Temperature: 0℃~45℃ Relative Humidity: 30%~75%
Supply Ability
- Supply Ability:
- 300 Set/Sets per Month
Packaging & Delivery
- Packaging Details
- Plywood Package
- Port
- Qingdao
- Picture Example:
-
- Lead Time :
-
Quantity(Sets) 1 - 1 2 - 10 >10 Est. Time(days) 15 20 To be negotiated
Product Description
INTRODUCTION:
Alpha APS CNC Router is manufactured using global state-of-the-art techniques with advanced engineering, workmanship and built to last with all steel construction and superior components such as precision linear bearings and rails. Key features are a 9KW(12HP) high frequency automatic tool changer spindle with 8-position tool rack, pneumatically retractable vacuum hood and multi-zone vacuum t-slot table. The system includes Servo motors and controls with a Taiwan industrial LNC controller.
The main advantage of the machine is the tool rack moving together with the machine gantry, which will save the tool change time.
The machine can cut about 50 pcs of wood board per 8 hour.
The main advantage of the machine is the tool rack moving together with the machine gantry, which will save the tool change time.
The machine can cut about 50 pcs of wood board per 8 hour.
It can process wood, MDF, chipboard, plywood. It is widely used in the cabinet making industry. And it also can process acrylic, plastic, soft metal and many other different materials.
Parameters | Standard Specifications APS-1325 |
X,Y,Z Working Area | 1300*2500*300mm |
Spindle Power | 9kw ATC air cooling spindle |
X,Y,Z Traveling Positioning Accuracy | ±0.02/2000mm |
Table Surface | Vacuum and T-slot |
X,Y,Z Rail and Transmission | X Y axis helical gear transmission, Z axis Taiwan TBI Ball Screw |
Max. Rapid Travel Rate | 60m/min |
Max. Working Speed | 40m/min |
Spindle Speed | 0-24000RPM |
Drive Motors | Leadshine servo motor and driver |
Working Voltage | AC380V/3PH/50Hz(option:220V) |
Command Language | G Code |
Operating System | Taiwan LNC |
Interface | USB |
Software capabilities | Option: Vectric Aspire, Type3, Ucancam, Artcam, Solidworks, etc. |
Running Environment | Temperature: 0℃~45℃ Relative Humidity: 30%~75% |
Detailed Images
The base frame is fabricated from heavy-duty tubular steel that is welded, precision machined and stress relieved so that the
foundation remains true and steady over the operational life of the machine.
foundation remains true and steady over the operational life of the machine.
The Alpha ATC CNC Router machine comes standard with a 9kw HQD or CC high frequency automatic tool changer spindle. This precision spindle requires no maintenance, uses industry standard ER collets and ISO 30 tool holders. Fully programmable speeds from 6000 to
24000 RPM, and comes complete with pneumatically retractable vacuum hood.
24000 RPM, and comes complete with pneumatically retractable vacuum hood.
# With Big screen
# Use keyboard + mouse operation
# Controllable single path 4 axis
# Support all kinds of pulse type drivers
# Interpolation is available for a variety of wood processing needs
# Support a variety of woodworking machine standard features
# Woodworking machine exclusive operation interface
# Support U disk
# Use keyboard + mouse operation
# Controllable single path 4 axis
# Support all kinds of pulse type drivers
# Interpolation is available for a variety of wood processing needs
# Support a variety of woodworking machine standard features
# Woodworking machine exclusive operation interface
# Support U disk
Composed of: servo drives and the servos move in all axes.
With this motor, the machine can realize high-precision machining at high speed.
With this motor, the machine can realize high-precision machining at high speed.
The machine adopts Taiwan Hiwin square rail, which is more than twice durable. And the use of high quality helical rack pinion,
makes it high precision..
makes it high precision..
Automatic tool calibration pad allows for easy and accurate “Z” zero position for single and multiple tool changes through the program.
The machine comes with a vacuum brush at the back of the machine beam. The function of the vacuum brush is to absorbs the small wood chips that have just been cut. Prevents the scum from affecting the vacuum sucking function. It will make the machine vacuum suck the material more firmly.
Vacuum table
The APS CNC Router has a 1 inch thick phenolic vacuum table surface mounted onto the steel base frame, keeping a rigid and consistent platform for your sheets and parts to be supported.
The vacuum table surface is multi-zoned which allows the operator to easily switch from full sheet processing to smaller part
processing, (which requires a smaller segmented area). Zones can be turned off easily via control valves on the front of the
machine. Gasketing can also be routed to accommodate various material sizes and styles.
The vacuum table surface is multi-zoned which allows the operator to easily switch from full sheet processing to smaller part
processing, (which requires a smaller segmented area). Zones can be turned off easily via control valves on the front of the
machine. Gasketing can also be routed to accommodate various material sizes and styles.
The APS Series Machine also includes a heavy-duty aluminum T-Slot profile in multiple locations across the table surface. This T-Slot accepts Alpha’s square M6 T-nuts.
7.5kw dry Rotary Vane Vacuum Pump Comes standard with motor starter, vacuum gauge, primary and secondary filter, check valve and
all necessary plumbing to connect to router.
all necessary plumbing to connect to router.
The Alpha AIS CNC Machine comes equipped with a tool holder clamp fixture, providing a much easier way of inserting and tightening
the CNC router bits into your tool holder. This method is safer and easier than using the common procedure of tightening the
collet nut with two wrenches while the tool holder is still in the spindle.
the CNC router bits into your tool holder. This method is safer and easier than using the common procedure of tightening the
collet nut with two wrenches while the tool holder is still in the spindle.
The Alpha AIS ATC Series CNC machine comes standard with three material pneumatic alignment stops. These pins allow the operator
to bank the edge of the material against them precisely aligning the material to the machine origin.
Figure on the right illustrates the CNC Router material alignment pins pop open and close for easy sheet alignment
to bank the edge of the material against them precisely aligning the material to the machine origin.
Figure on the right illustrates the CNC Router material alignment pins pop open and close for easy sheet alignment
High performance, small size
High-performance SVC control with high precision
Small size, about 70% of general machinery, saving installation space
Flexible digital input signal
Programmable bipolar signal input, compatible with AC and DC signal inputs.
- DC input voltage range 15-56VDC, compatible with 24, 36, 48VDC
- AC input voltage range 12-54VAC, compatible with 36, 48VAC
High-performance SVC control with high precision
Small size, about 70% of general machinery, saving installation space
Flexible digital input signal
Programmable bipolar signal input, compatible with AC and DC signal inputs.
- DC input voltage range 15-56VDC, compatible with 24, 36, 48VDC
- AC input voltage range 12-54VAC, compatible with 36, 48VAC
All the electrical components are housed and wired in a independent electrical enclosure. This allows for easy access and service when needed. All wiring is tagged so that when service is required, the customer can easily navigate the cabinet. In addition, the cabinet serves as a work bench for the tools required.
The Alpha ATC CNC Machine comes with a 3.5kw dust collector, which is powerful enough for collect the. It will make your workshop
without dust.
without dust.
